投影仪专用晶体振荡器Q3805CA10020400，这是一家历经无数磨难并通过自身的努力奋斗和信念，实现逆袭且获取巨大成就的知名制造商--它就是爱普生晶振公司，主要向市场提供优质的晶振产品，并且帮助用户解决在晶体行业所遇到的问题，随之又开发了EG-2121CA晶振，编码Q3805CA10020400，频率125.000000兆赫，输出WaveLVDS，电源电压2.38 ~ 2.62 V，尺寸(LxWxH)7.00 x 5.00 x 1.20 mm，工作温度0至+70°C，频率公差±100ppm，这是一款微型的爱普生有源晶振，OSC晶振，石英晶体振荡器，具备高稳定性能，适用于各个领域当中，包含投影仪，无线模块，智能家居等。

Product Number	差分晶振LVDS	Frequency	LxWxH	Output Wave	Supply Voltage	Ope Temperature
Q3805CA10018200	EG-2121CA	245.760000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10018400	EG-2121CA	195.312500 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10018500	EG-2121CA	212.500000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10018600	EG-2121CA	285.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	-5 to 85 °C
Q3805CA10018700	EG-2121CA	106.250000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10018800	EG-2121CA	265.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	-5 to 85 °C
Q3805CA10019100	EG-2121CA	312.500000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10019200	EG-2121CA	280.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10019300	EG-2121CA	360.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10019400	EG-2121CA	120.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10019500	EG-2121CA	240.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	-5 to 85 °C
Q3805CA10019600	EG-2121CA	280.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10019700	EG-2121CA	106.250000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10019900	EG-2121CA	375.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	-5 to 85 °C
Q3805CA10020000	EG-2121CA	166.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10020100	EG-2121CA	105.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10020200	EG-2121CA	622.080000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10020300	EG-2121CA	266.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10020400	EG-2121CA	125.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	0 to 70 °C
Q3805CA10020500	EG-2121CA	133.000000 MHz	7.00 x 5.00 x 1.20 mm	LVDS	2.375 to 2.625 V	-5 to 85 °C

爱普生晶振微型的有源晶振，贴片型高性能晶振，无线蓝牙晶振，兆赫频率元件，应用于时钟模块，智能家居，全球定位系统，因产品本身体积小，SMD编带型，可应用于高性能自动贴片焊接，被广泛应用到各种小巧的便携式消费电子数码时间产品，环保性能符合ROHS/无铅标准。
